Elephant Trunk Take-up Machine

Machine à enrouler à trompe d’éléphant

À partir de $1,000

Machine à enrouler de type trompe d’éléphant (XB-600) pour la collecte continue de fil.

Catégorie :

From $1,000

⚙
Personnalisation disponibleTous les paramètres peuvent être adaptés à vos exigences de production. Le prix final est établi selon vos spécifications confirmées.

Aperçu

La machine à enrouler à trompe d’éléphant enroule le fil en couronne à l’aide d’un guide rotatif en forme de trompe, produisant des couronnes propres et sans emmêlement, sans bobine. Couramment spécifiée comme machine à enrouler de produit fini pour les lignes de tréfilage rectiligne.

Caractéristiques principales

  • Produit des couronnes propres sans bobines
  • Collecte continue — aucun arrêt pour changer les bobines
  • Modèle XB-600
  • Adapté à l’acier et au fil à souder
  • Construction simple et robuste

Spécifications techniques

Modèle XB-600 Trompe d’éléphant
Application Réception continue des bobines de fil
Lignes compatibles Machines à tréfiler en ligne LT300–800

Envoyez-nous votre plage de diamètres de fil, le matériau et la production requise — nos ingénieurs confirmeront la spécification exacte et établiront un devis sous 24 heures.

Avis

Il n’y a pas encore d’avis.

Soyez le premier à laisser votre avis sur “Machine à enrouler à trompe d’éléphant”

Your email address will not be published. Required fields are marked *

Produits similaires

Request a Quote for This Machine

Send us your wire diameter, capacity and power supply requirements — we reply with price and lead time within 24 hours.

Send Your Requirements

Tell us what you need — we reply with price, lead time and shipping cost within 24 hours.

🔒 Your details are kept confidential and never shared. We reply within 24 hours.

Frequently Asked Questions

How do I match take-up capacity to my drawing machine?

Match it to the coil weight you actually handle. If the pay-off accepts 2.3 tons but the take-up fills at 800 kg, the line stops frequently. Line speed is also limited by the take-up, so an undersized take-up means the drawing machine never reaches its rated speed.

What is the difference between an I-wheel and an elephant trunk take-up?

An I-wheel take-up spools the finished wire onto a reel, which suits transport and storage. An elephant trunk take-up coils wire without a spool, which suits downstream processing where the coil is fed directly into another machine.

What spool sizes are available?

I-wheel take-up machines are available in 400, 630, 800 and 850 mm reel sizes, and vertical I-wheel units up to 1150 mm for large spools and heavy coils. The right size depends on the coil weight you need to handle.

Do I need equipment to move full spools?

Yes. A large vertical take-up produces a spool that needs handling equipment to move. If you do not have that equipment, a smaller I-wheel machine is the practical choice even where a larger one would be more efficient.

Can the take-up run continuously with the drawing machine?

It can, provided capacities are matched and the take-up speed follows the line speed. Tension control between the drawing machine and take-up matters, particularly on fine wire.

Is the take-up supplied with the drawing machine or separately?

Either. Take-up and pay-off equipment can be specified as part of a complete line or supplied separately to match a machine you already have. Give us the existing machine specification so the interface matches.
