Extension Machine (for round steel and threaded steel)

Machine d’extension (pour acier rond et acier fileté)

À partir de $1,000

Machine d’étirage pour l’amincissement de l’acier rond — universelle pour l’acier rond et l’acier fileté.

Catégorie :

From $1,000

⚙
Personnalisation disponibleTous les paramètres peuvent être adaptés à vos exigences de production. Le prix final est établi selon vos spécifications confirmées.

Aperçu

La machine d’étirage réduit le diamètre de la barre en acier rond avant tout traitement ultérieur, et convient également à l’acier rond et à l’acier fileté (déformé). Disponible en trois tailles couvrant Φ6–10 mm, Φ6–12 mm et Φ6–16 mm.

Caractéristiques principales

  • Universelle — fonctionne sur acier rond et fileté
  • Trois modèles : 550, 650, 750
  • Couvre Φ6–10 mm jusqu’à Φ6–16 mm
  • Entraînement de 18.5 kW à 37 kW
  • S’intègre aux lignes de redressage et de coupe

Spécifications techniques

Modèle 550 650 750
Puissance moteur 18.5 kW 22 kW 37 kW
Diamètre de bobine Φ550 Φ600 Φ800
Spécification Φ6–Φ10 Φ6–Φ12 Φ6–Φ16

Envoyez-nous votre plage de diamètres de fil, le matériau et la production requise — nos ingénieurs confirmeront la spécification exacte et le devis sous 24 heures.

Avis

Il n’y a pas encore d’avis.

Soyez le premier à laisser votre avis sur “Machine d’extension (pour acier rond et acier fileté)”

Your email address will not be published. Required fields are marked *

Produits similaires

Request a Quote for This Machine

Send us your wire diameter, capacity and power supply requirements — we reply with price and lead time within 24 hours.

Send Your Requirements

Tell us what you need — we reply with price, lead time and shipping cost within 24 hours.

🔒 Your details are kept confidential and never shared. We reply within 24 hours.

Frequently Asked Questions

What wire diameter range can these machines handle?

The range runs from small wire around 1.2 mm up to 25 mm rebar, depending on the model. Each machine has a stated straightening diameter range and cutting length range, both of which should be confirmed in writing before ordering.

How accurate is the cutting length?

Cutting length tolerance varies by model. Smaller machines are typically rated to about plus or minus 1 mm, while larger hub and hydraulic machines are commonly rated to within 5 mm. Straightening accuracy is usually stated separately, around 1 mm per metre.

Can it cut both round and threaded rebar?

Yes. Several models in the range are built for both round steel and threaded steel, and profile machines can also handle square, hexagonal and flat steel with the appropriate tooling. Confirm the material you need when specifying.

What is the difference between the hub type and the CNC hydraulic type?

Hub type machines use a rotating hub to straighten wire and are suited to a wide diameter range at moderate speed. CNC hydraulic machines use hydraulic cut-off with programmable length control, which suits repeat production runs and higher accuracy requirements.

How fast do they run?

Straightening speed is typically up to about 30 m/min on the larger machines, with small wire machines running faster. Actual output depends on cut length as much as line speed, since short cuts mean more cutting cycles per metre.

Can the machine be configured for our production line?

Yes. Cutting length range, motor power, voltage and control configuration can all be specified. Most machines in this range are built to order rather than supplied from stock.
